Technical Specifications
SIZE AND WEIGHT
Size 318mm X 264mm X 152mm
Weight 4.5kg
DISPLAY
12.1” Color TFT-LCD
Resolution 800 X 600 pixels or higher
POWER SUPPLY
Power Voltage AC 100-240V 50/60Hz
Power Imput ≤ 85VA
Fuse: T1.6AL/250V, Ф5X20 ( mm )
Safety class: Category I
BATTERY
Type: rechargeable Sealed Lead Acid cell, 12V/2.0AH
Charge time: ≤ 10 hours ( 2 batteries for 20 hours )
Operating time under normal use and full charge:
≥ 60 minutes ( 2 batteries for 120 minutes )
Operating time after the first alarm if low battery: 5-15 minutes
THERMAL RECORD ( OPTION )
Method: thermal dot array
Paper width: 50mm ( 1.97 in )
Paper Speed: 12.5/25/50 ( mm/sec )
Traces Maximum: 3 tracks
SYSTEM OUTPUT
Ethernet Network standard RJ45 socket
RF Wireless LAN: 433MHz, 10mW ( option )
Defibrillation Output: Option
Video Output: Option
ALARM
Three Level: Low, medium and high
Indication: Auditory and visual
Setup: Default and custom
Silence: All alarms can be silenced
Volume: 45~85 dB measured at 1 meter
TREND
Store & review 168 hours trend data and trend maps
Parameter option: HR, SpO2, NIBP, PR, Resp, CO2, Temp1,
Temp2, AA, N2O, O2, IBP1, IBP2, ST.
Cycle intervals of trend storage 1min, 2min, 3min, 4min, 5min,
10min, 15min, 20min, 25min, 30min.
STORE & REVIEWING
ECG: 30 minutes one important lead’s ECG waveform
Alarm: 1800 groups Alarm events reviewing
NIBP: 1000 groups NIBP measurement
Arrhythmia: 128 groups data ( 8 seconds ECG waveform )
ENVIRONMENT
Working temperature: 0~+40°C
Transportation and storage temperature: 20~+55°C
Relative humidity: Working ≤ 85% Transportation and storage ≤93%
Atmospheric pressure: Working 860~1060 hPa
Transportation and storage 500~1060 hPa
STANDARD CONFIGURATION:
ECG, HR, RESP, NIBP, SpO2, PR, TEMP, Battery Lead-acid
OPTION:
Litium battery, 2-TEMP, 2-IBP, Recorder, EtCO2 ( side stream, main stream ),
Anesthetic Gas, Nellcor SpO2, ICG
