KEY FEATURES
Slip-Free Safety Clamp
Clamp closes automatically when the programmed volume of blood is collected or if the flow rate is less than 20 mL per minute for more than 2 minutes
Special slot ensures the tube stays inside the clamp
Clamp can be closed manually in case of emergency
Detachable Tray
Tray continuously agitates the blood collection for uniform mixing of blood and anticoagulant solution
Integrated filter holder accommodates various types of bag sets
Magnetically attached tray is easily removable for cleaning
Removable tray protects the device by detaching in the event of a collision
Backlit LCD Display
Display shows programmed volume, collected volume, flow rate and device status, including battery level, manual clamping and pause functions.
Easy-to-Use Keypad
Keypad allows target volume selection of 350 mL or 450 mL with one touch.
LED Alerts
Lights and audible alarms indicate status of power, battery, draw flow, emergency clamping and end of collection.
Portable Design
Lightweight, compact size makes it perfect for mobile donations
Provides 12-hour or 90-collection continuous battery backup
Safety Features
Designed to meet all EN 60601-1 international safety requirements
Intelligent battery system protects the battery from overcharging or discharging
SPECIFICATIONS
Input voltage
D 601 monitor: 18 V, 3.3 A
Power adaptor: 100 V to 240 V AC, 50 Hz to 60 Hz
Classification
Protection against electrical shock: Class II; Internally powered
Operation
Continuous operation with intermittent loading
Power
70 VA max
Working environment
Temperature: 10 °C to 40 °C
Relative humidity: 30% to 75%
Atmospheric pressure: 700 hPa to 1,060 hPa
Storing and transportation
Temperature: 20 °C to 40 °C
Relative humidity: 20% to 90% with no condensation
Atmospheric pressure: 600 hPa to 1,060 hPa
Oscillation details
12 ± 2 RPM, motor-driven oscillation
Clamping mode
Motor-activated clamping
Volume setting ranges
Increments of 5 mL from 50 mL to 500 mL
Automatic storage and recall of set volume
Alarms/Indications
Audible/visible–Flow rate below 20 mL/min or above 180 mL/min
Audible/visible–Power failure
Audible/visible–Battery low
Audible/visible–Automatic clamping when flow rate sustained at less than 20 mL/min for more than two minutes
Audible/visible–End of collection
Display
Backlit LCD display: 20 characters × 4 lines
Time measurement
Time of collection is indicated at the end of every collection
Accuracy
± 2% of programmed volume
External dimensions in mm (W × D × H)
250 × 340 × 180
Weight
4.5 kg D 601
550 g power adaptor
Battery
14.8 V, 4.4 Ah lithium-ion rechargeable battery
