Principle
Impedance method for WBC, RBC and PLT counting
Cyanide free reagent for hemoglobin test
Performance
| Parameter | Linearity Range | Precision (CV %) | Carryover |
| WBC(10⁹/L) | 0-200 | ≤3.5% (4.0-6.9) | ≤0.5% |
| ≤2.0% (7.0 -15.0) | |||
| RBC(10¹²/L) | 0-8.00 | ≤1.5% (3.5-6.5) | ≤0.5% |
| HGB(g/L) | 0-280 | ≤1.5% (100 -180) | ≤0.5% |
| MCV(fL) | ≤1.0% (70 -110) | ||
| PLT(109/L) | 0-4000 | ≤5.0% (100 -149) | ≤1.0% |
| ≤4.0% (150 -500) |
Parameters
21 parameters: WBC, Lymph#, Mid#, Gran#, Lymph%, Mid%,
Gran%, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD,
PLT, MPV, PDW, PCT, P-LCR,P-LCC
3 histograms for WBC, RBC and PLT
Sample Volume
Prediluted mode 20 uL
Whole blood mode 9 uL
Throughput
70 samples per hour
Reagent
BeneSphera DILUENT
BeneSphera FL LYSE
BeneSphera CLEANSER
Display
10.4 inch TFT Touch Screen
Multi-language
Chinese, English, Spanish, Portuguese, Russian, French, Bahasa
Indonesia
Data Storage Capacity
Up to 500,000 results including numeric and graphical information
Communication
LAN Port supports HL7 protocol
Support bi-directional LIS
Interface
4 USB port (for external printer, software upgrade, barcode reader,
WIFI adapter,keyboard and mouse), LAN port (1)
Printout
Thermal recorder, 50 mm wide paper, various printouts formats
External printer optional
Operating Environment
Temperature: 10°C~40°C
Humidity: 10%~90%
Air pressure: 70kPAN106kPa
Power Requirement
100V-240V
≤300VA
50Hz/60Hz
Dimension and Weight
Dimension: Depth(410 mm) x width(300 mm) x height(400 mm)
Weight: ≤20Kg
