FEATURES
- Flow rate : 0.1~1500 ml/h
- Infused Volume : 0.1~9999 ml
- Bolus rate : 1~1500 ml/h
- K.V.O : 0.1~9 ml/h
- Occulsion Level : 9 Level (60-850 mmHg)
- Battery : Operating 6 hour, Recharging 5 hour
- Weight : 1.8 kg
| Pumping Mechanism | Peristaltic Transit Finger | ||
| Flow Rate | 0.1 ~ 1200 ml/h | Micro (On): 0.1 ~ 999.9 ml/h (in 0.1 ml/h increments) 1000 ~ 1200 ml/h (in 1 ml/h increments) Micro (Off): 1 ~ 1200 ml/h (in 1 ml/h increments) | |
| Accuracy | ±5% (BD I.V Set, AN122) Measured every hour at room temperature (25℃) using water or saline solution (above 1.0 ml/h of flow rate).
* Accuracy may differ depending on the type of medical fluid and IV Set & Feeding Set. |
||
| Infusion Range | Total Vol. | 0.1 ~ 9999 ml or infinity | Micro (On): 0.1 ~ 999.9 ml (in 0.1 ml increments) 1000 ~ 1200 ml (in 1 ml increments) Micro (Off): 1 ~ 9999 ml (in 1 ml increments) |
| Infused Vol. | 0.0 ~ 9999 ml | 0.0 ~ 999.9 ml (in 0.1 ml increments) 1000 ~ 9999 ml (in 1 ml increments) | |
| Bolus Rate (Purge) | 700 ml/h (default) – 1 ~ 1200 ml/h | ||
| Bolus Volume (Purge) | 5 ml (default) – 1 ~ 9999 ml | ||
| KVO Rate | 1 ml/h (default) 1 ~ 9 ml/h | At flow rate 1.0 ~ 1200 ml/h | |
| 0.1 ml/h (default) | At flow rate 0.1 ~ 0.9 ml/h | ||
| Occlusion pressure | 100mmHg ~ 950mmHg(13~126kPa) | ||
| Display | 7 segments (4 digits * 3 lines) | ||
| Alarms | * Air Bubble alarm
* Occlusion alarm (detection capacity: 100 ~ 950 mmHg) – 9 adjustable steps for downstream occlusion * Door Open alarm * Battery Low, Battery Empty alarm * Abnormal Drop alarm * Infusion Complete alarm (automatic switch-over to KVO feature) * AC/DC Power Shut-off alarm * Start Reminder alarm (pause set time elapsed) * Standby alarm (at an interval of 2 minutes when not infusing) * Near complete alarm * The pump stops operating when alarms go off except for battery low, start reminder and infusion completion signals. * Malfunction – The status of the pump is displayed and an alarm goes off. |
||
| Safety Features | * Door Open: Infusion is unavailable when the door is open.
* Key Lock: Only the START, STOP and ON/OFF keys work. * Air Sensor: Detects air bubbles. * Occlusion Sensor: Detects clogging of the tube. * Drop Sensor: Detects medical fluid drops. * Nurse Call: Monitoring is possible if an alarm goes off. |
||
| Other Functions | * Time Mode: Calculates the flow rate by setting the infusion time.
* Gtt Mode: Calculates the flow rate by setting the number of infusion drops. * Dosage Mode: Calculates the flow rate by setting the dosage. * Titration: Flow rate can be altered during infusion (available only when the remaining time for infusion is more than 5 minutes). * Battery Low, Empty: Alarms go off 30 minutes and 3 minutes before the battery goes flat. * Date and Time: The date and time can be checked without a power supply, since a clock is installed. * Pause: Infusion resumes automatically after preset time elapses when the pause key is pressed and infusion is stopped (default 24 hours, setting range from 1 minute to 24 hours in 1 minute units). * Event History: Saves up to 2000 and it can view by separate PC utility. Please refer service manual for detailed usage of event history. * Alarm log event: Saves up to 50 in the pump and it can view in the pump at setting mode1. Please refer service manual for detailed usage of alarm log event. * The electronic data of the infusion pump are stored for over 2 years even if it has been turned off. |
||
| Power | * AC 100~240 VAC, 50/60 Hz (Fuse: 250 V, T3.15 A)
* DC 12V (500 mA) * Ni-MH Rechargeable Battery – 2,000 mA/h, AA, 1.2V x 10cell – operating time – approx. 6 hours at a flow rate of 25 ml/h – recharging time – approx. 5 hours |
||
| Power Requirements | 35VA | ||
| Protection Type | * Protection from electric shock: Class â…
* Protection capacity for electric shock: Type CF Protection from liquid infiltration: IPX 2 (drip-proof) |
||
| Size (D×W×H) | 120×130×206 mm | ||
| Weight | approx. 1.7 kg | ||
| Operating Environment | Temperature: 10~ 40℃, Humidity: 20 ~ 90% RH Atmospheric Pressure: 70 ~ 106 kPa (525.04 ~ 795.06 mmHg) | ||
| Storage Environment | Temperature: -10 ~ 60℃, Humidity: 10 ~ 95% Atmospheric Pressure: 65 ~ 120 kPa (487.54 ~ 900.07 mmHg) | ||
